Features
360 degree rotator can Rolling over 360º,and can be widely used in food industry, chemical industry, sanitation industry, recycle industry, smelt casting industry, etc.
* Proven durable construction design, unique rotating driven system, meet the high strength continuous operation.
* Strong rotating driving torque achieved the stable and reliable rotating function.
* Hydraulic motor fixed with reversible hydraulic lock, any angle position of lock function.
Products Name | Capacity @ Load Center | Item No. | Truck/Rotator Mounting Class | Rotator/Forks | Carriage Width | Fork Max Spacing | Fork Min Spacing | Overall Width | Weight |
Rotator | 1700@500 | RRB20D-001A | II | II | 815 | 705 | 610 | 840 | 188 |
1600@500 | RRB20D-002A | II | II | 815 | 705 | 610 | 840 | 254 | |
1600@500 | RRB20D-003A | II | II | 815 | 705 | 610 | 840 | 259 | |
1600@500 | RRB20D-004A | II | II | 815 | 705 | 610 | 840 | 268 | |
1600@500 | RRB20D-005A | II | II | 815 | 705 | 610 | 840 | 277 | |
2200@500 | RRB20D-006A | II | II | 815 | 705 | 813 | 840 | 300 | |
2200@500 | RRB20D-007A | II | II | 940 | 835 | 813 | 965 | 309 | |
3000@500 | RRB30D-008A | II | II | 940 | 855 | 813 | 965 | 313 | |
3000@500 | RRB30D-008B | III | II | 940 | 855 | 813 | 965 | 329 | |
3000@500 | RRB30D-009A | II | II | 1145 | 1060 | 813 | 1170 | 327 | |
3000@500 | RRB30D-009B | III | II | 1145 | 1060 | 813 | 1170 | 343 | |
3500@500 | RRB35D-010B | III | III | 1065 | 990 | 813 | 1090 | 390 | |
3500@500 | RRB35D-011B | III | III | 1220 | 1140 | 813 | 1245 | 406 |
![]() |
